15KPA Series > TVS Diodes

The 15KPA Series is designed specifically to protect sensitive electronic equipment

from voltage transients induced by lightning and other transient voltage events.

Features:


• Halogen-Free and RoHS compliant
• Typical maximum temperature coefficient ΔV_BR = 0.1% — V_BR@25°C
• Glass passivated chip junction in P600 package
• 15000W peak pulse capability at 10—1000µs waveform, repetition rate (duty cycles):0.01%
• Fast response time: typically less than 1.0ps from 0 Volts to BV min
• Excellent clamping capability
• Low incremental surge resistance
• Typical IR less than 2µA above 36V
• High temperature soldering guaranteed: 265°C./10 seconds/ 0.375" (9.5mm)
•  lead length, 51bs., (2.3kg) tension
• Plastic package has Underwriters Laboratory Flammability classification 94V-O
• Matte Tin Lead-free plated

Catalog #	VR (Vso)	Watts (W)	IPP 10x1000μs (A)	MIN VBR@IT (V)	MAX VBR@IT (V)	Vc (V)	IT (mA)	Ir@Vso (μA)	Max Temp (deg C)	Stock	Samples	Compare
15KPA100	100	15000	93	105.3	128.7	169.365	5	2	150	Check	Order
15KPA100A	100	15000	93.6	111.7	122.3	161.3	5	2	150	Check	Order
15KPA100C	100	15000	93	105.3	128.7	169.365	5	2	150	Check	Order
15KPA100CA	100	15000	93.6	111.700	122.300	161.3	5	2	150	Check	Order
15KPA110	110	15000	84	115.83	141.57	187.53	5	2	150	Check	Order
15KPA110A	110	15000	84.5	122.9	134.5	178.6	5	2	150	Check	Order
15KPA110C	110	15000	84	115.83	141.57	187.53	5	2	150	Check	Order
15KPA110CA	110	15000	84.5	122.9	134.5	178.6	5	2	150	Check	Order
15KPA120	120	15000	78	126.36	154.44	201.915	5	2	150	Check	Order
15KPA120A	120	15000	78.5	134	146.8	192.3	5	2	150	Check	Order
15KPA120C	120	15000	78	126.36	154.44	201.915	5	2	150	Check	Order
15KPA120CA	120	15000	78.5	134	146.8	192.3	5	2	150	Check	Order
15KPA130	130	15000	72	136.89	167.31	218.715	5	2	150	Check	Order
15KPA130A	130	15000	72.5	145.2	159	208.3	5	2	150	Check	Order
15KPA130C	130	15000	72	136.89	167.31	218.715	5	2	150	Check	Order
15KPA130CA	130	15000	72.5	145.2	159	208.3	5	2	150	Check	Order
15KPA150	150	15000	62	157.995	193.105	253.995	5	2	150	Check	Order
15KPA150A	150	15000	62.4	167.6	183.5	241.9	5	2	150	Check	Order
15KPA150C	150	15000	62	157.995	193.105	253.995	5	2	150	Check	Order
15KPA150CA	150	15000	62.4	167.6	183.5	241.9	5	2	150	Check	Order
15KPA160	160	15000	58	168.48	205.92	271.53	5	2	150	Check	Order
15KPA160A	160	15000	58.4	178.7	195.7	258.6	5	2	150	Check	Order
15KPA160C	160	15000	58	168.48	205.92	271.53	5	2	150	Check	Order
15KPA160CA	160	15000	58.4	178.700	195.700	258.6	5	2	150	Check	Order
15KPA17	17	15000	512	17.901	21.879	30.765	50	5000	150	Check	Order
15KPA170	170	15000	55	179.01	218.79	286.335	5	2	150	Check	Order
15KPA170A	170	15000	55.4	189.9	207.9	272.7	5	2	150	Check	Order
15KPA170C	170	15000	55	179.01	218.79	286.335	5	2	150	Check	Order
15KPA170CA	170	15000	55.4	189.9	207.9	272.7	5	2	150	Check	Order
15KPA17A	17	15000	515.4	18.99	20.79	29.3	50	5000	150	Check	Order
15KPA17C	17	15000	512	17.901	21.879	30.765	50	5000	150	Check	Order
15KPA17CA	17	15000	515.4	18.99	20.79	29.3	50	5000	150	Check	Order
15KPA18	18	15000	485	18.954	23.166	32.445	50	5000	150	Check	Order
15KPA180	180	15000	52	184.05	224.95	302.925	5	2	150	Check	Order
15KPA180A	180	15000	52.3	201.1	207.9	288.5	5	2	150	Check	Order
15KPA180C	180	15000	52	189.54	231.66	302.925	5	2	150	Check	Order
15KPA180CA	180	15000	52.3	201.1	220.1	288.5	5	2	150	Check	Order
15KPA18A	18	15000	488.7	20.11	22.01	30.9	50	5000	150	Check	Order
15KPA18C	18	15000	485	18.954	23.166	32.445	50	5000	150	Check	Order
15KPA18CA	18	15000	488.7	20.11	22.01	30.9	50	5000	150	Check	Order
15KPA20	20	15000	437	21.06	25.74	36.015	20	1500	150	Check	Order
15KPA200	200	15000	47	210.6	257.4	335.055	5	2	150	Check	Order
15KPA200A	200	15000	47.3	223.4	244.6	319.1	5	2	150	Check	Order
15KPA200C	200	15000	47	210.6	257.4	335.055	5	2	150	Check	Order
15KPA200CA	200	15000	47.3	223.4	244.6	319.1	5	2	150	Check	Order
15KPA20A	20	15000	440.2	22.34	24.46	34.3	20	1500	150	Check	Order
15KPA20C	20	15000	437	21.06	25.74	36.015	20	1500	150	Check	Order
15KPA20CA	20	15000	440.2	22.34	24.46	34.3	20	1500	150	Check	Order
15KPA22	22	15000	404	132.152	161.519	38.955	10	500	150	Check	Order
15KPA220	220	15000	42	231.66	283.14	373.8	5	2	150	Check	Order
15KPA220A	220	15000	42.4	245.7	269.1	356	5	2	150	Check	Order
15KPA220C	220	15000	42	231.660	283.140	373.8	5	2	150	Check	Order
15KPA220CA	220	15000	42.4	245.7	269.1	356	5	2	150	Check	Order
15KPA22A	22	15000	407	24.57	269.1	37.1	10	500	150	Check	Order
15KPA22C	22	15000	404	23.166	28.314	38.955	10	500	150	Check	Order
15KPA22CA	22	15000	407	24.57	26.91	37.1	10	500	150	Check	Order
15KPA24	24	15000	369	25.272	30.888	42.735	5	150	150	Check	Order
15KPA240	240	15000	39	252.72	308.88	403.83	5	2	150	Check	Order
15KPA240A	240	15000	39.3	268.1	293.5	384.6	5	2	150	Check	Order
15KPA240C	240	15000	39	252.72	308.88	403.83	5	2	150	Check	Order
15KPA240CA	240	15000	39.3	268.100	293.500	384.6	5	2	150	Check	Order
15KPA24A	24	15000	371	26.81	29.35	40.7	5	150	150	Check	Order
15KPA24C	24	15000	369	25.272	30.888	42.735	5	150	150	Check	Order
15KPA24CA	24	15000	371	26.81	29.35	40.7	5	150	150	Check	Order
15KPA26	26	15000	341	27.378	33.462	46.2	5	50	150	Check	Order
15KPA260	260	15000	36	273.78	334.62	437.535	5	2	150	Check	Order
15KPA260A	260	15000	36.2	290.4	318	416.7	5	2	150	Check	Order
15KPA260C	260	15000	36	273.78	334.62	437.535	5	2	150	Check	Order
15KPA260CA	260	15000	36.2	290.4	318	416.7	5	2	150	Check	Order
15KPA26A	26	15000	343.2	29.04	31.8	44	5	50	150	Check	Order
15KPA26C	26	15000	341	27.378	33.462	46.2	5	50	150	Check	Order
15KPA26CA	26	15000	343.2	29.04	31.8	44	5	50	150	Check	Order
15KPA28	28	15000	316	29.484	36.036	49.875	5	25	150	Check	Order
15KPA280	280	15000	33	294.84	360.36	477.225	5	2	150	Check	Order
15KPA280A	280	15000	33.2	312.8	342.4	454.5	5	2	150	Check	Order
15KPA280C	280	15000	33	294.84	360.36	477.225	5	2	150	Check	Order
15KPA280CA	280	15000	33.2	312.8	342.4	454.5	5	2	150	Check	Order
15KPA28A	28	15000	317.9	31.28	34.24	47.5	5	25	150	Check	Order
15KPA28C	28	15000	316	29.484	36.036	49.875	5	25	150	Check	Order
15KPA28CA	28	15000	317.9	31.28	34.24	47.5	5	25	150	Check	Order
15KPA30	30	15000	296	31.5945	38.6155	53.235	5	15	150	Check	Order
